Design a webpage using a table

Creating a Simple Table

You have to use the codes given below to create a table of two columns and two rows. Step by step we will add more columns and rows to this table and finally we will create a full functional website of several pages. Lets learn how to create a webpage using the codes given below.

<!DOCTYPE html>
<html>

<head>
<title>Learn Website Designing</title>
</head>

<body>
<table align="center" border="1" style="width: 100%;">
<tbody align="center">
<tr><!--codes for the first row-->
<td>A</td><td>B</td>
</tr><!--end of the codes for the first row-->

<tr><!--codes for the second row-->
<td>A1</td><td>B1</td>
</tr><!--end of the codes for the second row-->
</tbody>
</table>
</body>

</html>
Note: The Ash Colored Codes are not important and/or necessary.

Website Designing,Formatting Table,Webpage using Table


You will get a table as showing below.
AB
A1B1

Explanation of the codes

To create a table I have used the <table> tag in the first line. I have used the attributes align="center", border="1" and style="width: 100%;". That's why the table will be placed in the center position, the width of the table will be 100% according to the webpage size and there will be a border of 1px.

I have used align="center" but you may also use align="left" or align="right". The value for the width attribute may be 80% or 700px. You have to use the closing tag </table> for the opening tag <table>.

In the second line I have used <tbody align="center"> so that all the text of the cells stay in the center position. In the first line I have also used the same attribute align="center" but for the table position only. If you want to show the text in the center position then you have to use <tbody align="center">.

Then in the third line I have used the tag <tr> to create a row and then <td></td> to create a cell. Thus I have used <tr><td>A</td><td>B</td></tr> to create a row and two columns inside of the row. <td>A</td> is for the first column and <td>B</td> for the second column. Thus I have created another row with two columns by the codes <tr><td>A1</td><td>B1</td></tr>.


Add an Extra Row and an Extra Column

Now we will add one more column and one more row with the above table. So we have to use the following codes given below in the box.

<tr><!--codes for the first row-->
<td>A</td><td>B</td><td>C</td>
</tr><!--end of the codes for the first row-->

<tr><!--codes for the second row-->
<td>A1</td><td>B1</td><td>C1</td>
</tr><!--end of the codes for the second row-->

<tr><!--newly added codes for the third row-->
<td>A2</td><td>B2</td><td>C2</td>
</tr><!--end of the codes for the third row-->

Now we will get the table given below.
ABC
A1B1C1
A2B2C2

Create a Table of 10 Rows and 6 Columns

Following the above tricks we will now create a new table with six columns and 10 rows. Later we will change it to a general webpage with several buttons, pages etc. Try yourself to create a table as shown below.

ABCDEF
A1B1C1D1E1F1
A2B2C2D2E2F2
A3B3C3D3E3F3
A4B4C4D4E4F4
A5B5C5D5E5F5
A6B6C6D6E6F6
A7B7C7D7E7F7
A8B8C8D8E8F8
A9B9C9D9E9F9

If you fail then you may use the codes given below.
 <table align="center" border="1" style="width: 100%;">
<tbody align="center">
<tr>
<td>A</td><td>B</td><td>C</td><td>D</td><td>E</td><td>F</td>
</tr>
<tr>
<td>A1</td><td>B1</td><td>C1</td><td>D1</td><td>E1</td><td>F1</td>
</tr>
<tr>
<td>A2</td><td>B2</td><td>C2</td><td>D2</td><td>E2</td><td>F2</td>
</tr>
<tr>
<td>A3</td><td>B3</td><td>C3</td><td>D3</td><td>E3</td><td>F3</td>
</tr>
<tr>
<td>A4</td><td>B4</td><td>C4</td><td>D4</td><td>E4</td><td>F4</td>
</tr>
<tr>
<td>A5</td><td>B5</td><td>C5</td><td>D5</td><td>E5</td><td>F5</td>
</tr>
<tr>
<td>A6</td><td>B6</td><td>C6</td><td>D6</td><td>E6</td><td>F6</td>
</tr>
<tr>
<td>A7</td><td>B7</td><td>C7</td><td>D7</td><td>E7</td><td>F7</td>
</tr>
<tr>
<td>A8</td><td>B8</td><td>C8</td><td>D8</td><td>E8</td><td>F8</td>
</tr>
<tr>
<td>A9</td><td>B9</td><td>C9</td><td>D9</td><td>E9</td><td>F9</td>
</tr>
</tbody></table>

Add <tr></tr> tags to create more rows and used <td></td> tags to create more columns.


Plan for a Webpage

The cells A, B, C, D, E and F will be the banner of the webpage and A1, B1, C1, D1, E1 and F1 will be the menu for the webpages. The other cells A2, B2, C2, D2, E2 and F2 will be used to show the current news or important messages. And the cells A3, A4, A5, A6 and A7 will be used for the side menus. And finally the others cells will the main blank portion of the page where the main content will be shown.

ABCDEF
A1B1C1D1E1F1
A2B2C2D2E2F2
A3B3C3D3E3F3
A4B4C4D4E4F4
A5B5C5D5E5F5
A6B6C6D6E6F6
A7B7C7D7E7F7
A8B8C8D8E8F8
A9B9C9D9E9F9

The table given below is the expected table to turn it to a webpage.
A
A1B1C1D1E1F1
A2
A3B3
A4
A5
A6
A7
A8
A9

The necessary codes for the above table is given below.
<table align="center" border="1" style="width: 100%;">
<tbody align="center">
<tr>
<td colspan="6">A</td>
</tr>
<tr>
<td>A1</td><td>B1</td><td>C1</td><td>D1</td><td>E1</td><td>F1</td>
</tr>
<tr>
<td colspan="6">A2</td>
</tr>
<tr>
<td>A3</td><td colspan="5" rowspan="7">B3</td>
</tr>
<tr>
<td>A4</td>
</tr>
<tr>
<td>A5</td>
</tr>
<tr>
<td>A6</td>
</tr>
<tr>
<td>A7</td>
</tr>
<tr>
<td>A8</td>
</tr>
<tr>
<td>A9</td>
</tr>
</tbody>
</table>

Final Touch for the Webpage

Fairytips
This website is full of HTML Tutorial. You will also learn more about Website Designing from this site. Just stay with me and learn to design a website easily.
HomeHTMLCSSJAVAPHPAbout Me
Learn HTML
ASP.NETYour Content Here...
MySQL
XML
XHTML
Ads Here
Text Board
More...

The codes for the above table is given below.
<table align="center" border="0" style="width: 100%;">
<tbody>
<tr>
<td align="align" bgcolor="45818e" colspan="6"><blockquote>
<h1>
Fairytips</h1>
This website is full of HTML Tutorial. You will also learn more about Website Designing from this site. Just stay with me and learn to design a website easily.</blockquote>
</td>
</tr>
<tr align="center" bgcolor="45818e">
<td width="15%"><span style="color: #f1f1f1;" onmouseover="menu">Home</span></td>
<td><span style="color: #f1f1f1;">HTML</span></td>
<td><span style="color: #f1f1f1;">CSS</span></td>
<td><span style="color: #f1f1f1;">JAVA</span></td>
<td><span style="color: #f1f1f1;">PHP</span></td>
<td><span class="Apple-style-span" style="color: #f1f1f1;">About Me</span></td>
</tr>
<tr>
<td colspan="6"><marquee>Learn HTML</marquee></td>
</tr>
<tr>
<td align="center" bgcolor="45818e">ASP.NET</td>
<td colspan="5" rowspan="7" valign="top">Your Content Here...</td>
</tr>
<tr>
<td align="center" bgcolor="45818e">MySQL</td>
</tr>
<tr>
<td align="center" bgcolor="45818e">XML</td>
</tr>
<tr>
<td align="center" bgcolor="45818e">XHTML</td>
</tr>
<tr>
<td align="center" bgcolor="45818e">Ads Here </td>
</tr>
<tr>
<td align="center" bgcolor="45818e">Text Board </td>
</tr>
<tr>
<td align="center" bgcolor="45818e">More...</td>
</tr>
</tbody>
</table>

Finally all the codes for the last table is given in the above box. You can create the table using these codes, copy the codes and paste them inside the <body> and </body> tags. Then save the webpage and open it in a web browser.
